DS-3WF0FA-5AC/O, 5GHz Wireless bridge 360degrees, 1Km

The Hikvision DS-3WF0FA-5AC/O is a high-performance 5GHz wireless AP bridge ideal for outdoor applications such as CCTV and industrial environments. With an impressive wireless transmission distance of up to 1 km and a speed of 867 Mbps via the 802.11ac standard, this bridge provides excellent performance for point-to-multipoint connections.

Algemeen

• Product dimensions (W × H × D): 103.6 mm × 58.3 mm × 198.4 mm (4.1'' × 2.3'' × 7.8'')
• Packing dimensions (W × H × D): 550 mm × 238 mm × 167 mm (21.6" × 9.3" × 6.5")
• Net weight: 0.3 kg (0.66 lb)
• Gross weight: 3.5 kg (7.71 lb)
• Container contents:
  • Wireless Bridge × 1
  • Power adapter × 1
  • Power cable × 1
  • Regulatory and Safety Information × 1
  • Quick start guide × 1
  • Screw package × 1
  • Binding tape × 2
  • Antenna × 1
• Packaging method: single unit packing
• Operating temperature: -30 °C to 60 °C (-22 °F to 140 °F)
• Operating humidity: 5% to 95% (no condensation)
• Storage temperature: -40 °C to 80 °C (-40 °F to 176 °F)
• Storage humidity: 5% to 95% (no condensation)
• Installation mode: Pol-mounted
• Ingression protection: IP55
• Power consumption: 2.65 W (typical, 1-channel 2MP IPC), Max. 4.5 W
• Wireless Parameter
  • Maximum air interface transmission rate: ≤ 867 Mbps
  • Wireless standard: IEEE 802.11/a/n/ac
  • Operating frequency range: 5150 MHz ~ 5250 MHz, 5250 MHz ~ 5350 MHz, 5470 MHz ~ 5725 MHz, 5725 MHz ~ 5825 MHz (Note: Available channels may vary depending on local regulations)
  • Antenna gain: 10 dBi
  • Antenna angle:
    • (H) Radiation width [3 dB] 360°
    • (V) Radiation width [3 dB] 8°
  • Transmit power: 22 dBm @11ac MCS0 (Note: Transmit power may vary depending on local regulations)
  • Reception sensitivity: -84±2 dBm @AC80-MCS0
  • Transmission speed:
    • PTP: 160 Mbps/0.5 KM (AC80), 160 Mbps/1 KM (AC80)
    • PTMP (1 to 8): 110 Mbps/1 KM (AC80)
  • PoE power supply:
    • PoE port: PoE IN/LAN 1
    • PoE distance: 100 m
• Hardware Parameter
  • Network interface: 2 × 1000 Mbps RJ45 ports
  • LED indicator:
    • Power indicator
    • LAN-indicator
    • Signal intensity indicator
  • Reset: Hardware reset button
  • Power supply: 48V 0.33A PoE or PoE(802.3af) 36～57V 0.13A
• Software Function
  • Application Functions: TDMA, DFS, TPC, IFM, IPM
  • Channel width: 20/40/80 MHz
  • Channel selection: Auto/manual selection
  • Network protocol:
    • NTP (network time synchronization)
    • SADP (automatic IP address lookup)
    • HTTPS (web management)
    • SSH (debugging)
  • Security mode: WPA2-PSK
  • Security mechanism: wireless network name hidden
  • Management method: Web, iVMS-4200, HCP
  • Upgrade: Web, iVMS-4200, HCP
  • System log: Syslog, Information Control Center
